GZ5F electromagnetic vibrating feeder

GZ5F electromagnetic vibrating feeder adopts the electromagnetic drive principle to make the material move forward in a linear micro-vibration state in the trough. The equipment can realize uniform, continuous or quantitative material delivery. It is usually equipped with a feeding trough of about 80mm wide and an adaptation frequency range of about 12-13Hz, which is suitable for small and medium-sized batch feeding applications. The equipment can be operated alone or integrated into an automation system. It has the characteristics of precise control, reliable operation, and small footprint. It is particularly suitable for process scenarios with high requirements for feeding accuracy.

The overall structure of the GZ5F electromagnetic vibrating feeder is compact, mainly composed of electromagnetic excitation components, elastic support system, feeding trough body, base and electronic control unit. When the exciter is working, it generates periodic magnetic force, drives the trough to generate high-frequency micro-vibration, and drives the material to be transported forward. The amplitude and feeding amount can be flexibly adjusted according to the process needs, with simple operation and fast response speed. The spring support not only effectively reduces vibration, but also improves the operation stability. Its trough structure design takes into account both versatility and adaptability, and is suitable for the stable conveying of fine powder, granules, small blocks or mixed materials.

GZ5F electromagnetic vibrating feeder selection

In the selection process of GZ5F electromagnetic vibrating feeder, the material characteristics, required feeding amount and equipment installation environment should be comprehensively considered. For powder, granules or small block materials, it is necessary to clarify their particle size, specific gravity and fluidity in order to select the appropriate amplitude, trough structure and drive parameters. GZ5F is suitable for continuous or intermittent feeding of small and medium batches of materials. The standard feeding capacity range is 0.5-20kg/min, which is suitable for a variety of production rhythms. If the conveying material is corrosive or has high requirements for cleanliness, 304 or 316L stainless steel can be selected; if precise control and system integration are required, it is recommended to configure a frequency modulation controller or PLC interface to improve the automation level and feeding stability.

Hopper and rack materials: Carbon steel (with anti-corrosion paint) or high-grade food-grade 304/316L stainless steel can be used to meet the requirements of corrosive materials and food safety levels.

Electromagnetic exciter casting: Made of high-temperature resistant aluminum alloy or cast iron, it has excellent heat dissipation effect, compact structure, and is suitable for continuous operation.

Spring bracket: Made of high-strength steel or spring steel to ensure vibration reliability and stability.

Sealing and protection level: Standard IP55 and above, optional waterproof and dustproof cover; closed structure can be selected for food and pharmaceutical application scenarios to reduce external interference.

As a small electromagnetic feeding equipment with compact structure, high precision, small footprint and flexible installation, GZ5F electromagnetic vibrating feeder performs well in the field of precision feeding of powder, granules and powder-granule mixtures. It generates high-frequency vibration through the electromagnetic exciter, which can achieve 0-100% quantitative continuous feeding, supports carbon steel and food-grade stainless steel materials, and is suitable for PLC control and various process requirements. Typical feeding capacity ranges from trace 0.5kg/min to 20kg/min.
